Features:
>> Two working mode choices: wrapping, or wrapping with top sheet dispensing.
>> PLC controlled, easy wrapping program setting.
>> Automatic stretch film clamp & cut, pneumatically driven.
>> Remote control device fitted. Machine start on control panel or remote controller.
>> Automatic film welding device for perfect film tail handling.
>> Film tension, turntable speed & carriage speed adjustable on panel.
>> Power stretch film carriage, ratio 250%, film savings.
>> Automatic wrapping according to pre-set parameters. Manual wrap mode as an option.
>> Auto height detection, machine home position, forklift sockets for easy moving.
>> Multiple safety protection measures for ensured operator safety.

Specifications:

Turntable diameter: 1800mm
Wrapping height: 2100mm
Loading weight: 2000kgs
Packing speed: 20-30 pallets/hour
Turntable speed: 3-15rpm, turntable soft start & soft stop
Turntable Height: 136mm
Air Pressure: 0.4-0.7Mpa
Top dispensing unit lifting speed: 5m/min
Top sheet pulling speed: 12m/min
Top sheet size: Width 1700mm,Length variable
Cut method: instant heater
Wrapping settings: wrapping cycles /top wraps /bottom wraps /overwrap
Carriage speed: 5m/min max
Power: 3PH 380VAC, 50/60Hz, 20A, 3kw
Machine Dimensions: 2960 x 2625 x 3100
Machine Weight: 1500kg
Film type: stretch film thickness 17-35microns, width 450-500mm, paper core 76mm, max weight 15kgs
Top Sheet type: PE film, thickness 50-75microns, width1600-1800mm, net weight 120kgs max
