Features:
>> PLC controlled, easy wrapping program setting.
>> Automatic stretch film clamp & cut, pneumatically driven.
>> Remote control device fitted. Machine start on control panel or remote controller.
>> Automatic film welding device for perfect film tail handling.
>> Film tension, turntable speed & carriage speed adjustable on panel.
>> Power stretch film carriage, ratio 250%, film savings.
>> Automatic wrapping according to pre-set parameters. Manual wrap mode as an option.
>> Auto height detection, turntable home position, forklift sockets for easy moving.
>> Dual limit switches on top & bottom to provide better safety protections.
Specifications:
Wrap speed: 30 – 50 pallets/hour
Turntable diameter: 1800mm
Turntable speed: 3 - 15rpm, soft start & stop
Turntable height: 136mm
Max load weight: 2000kgs
Wrap height: 2100mm
Clamper type: scissor type clamper
Cutter type: instant heater
Wrapping settings: wrapping cycles /top wraps /bottom wraps /overwrap
Carriage speed: 5 meters/min max
Turntable motor: 0.75kw
Pre-stretch motor: 0.2kw
Carriage lifter motor: 0.37kw
Power: 1PH 220VAC, 50/60Hz
Film type: stretch film thickness 17-35microns, width 450-500mm, paper core 76mm, max weight 15kgs
